Feature:
The powder coating machine adopts the special flow guiding device on the spraying nozzle to increase the powder adhesive capability to avoid powder fall down & powder scatter, to achieve the good coating quality
Adopts the intelligent air controlling system to supply the stable airflow resource to realize the even and neat powder spraying layer.
Adopts the high friction resistance and anti-static material, automatic static high-low voltage controlling system to do the micro-control and adjustment on the coating thickness.
Unique powder arm design, can be quickly dismantled, can be adjusted independently from different direction and position to save the maintenance time.
With HMI operation, fully automatic controlling system, easy to operate.
Compact one machine design, save space, convenient to link with several can making lines via different pipe system, able to work with different lines without moving the position of the powder coating machine.
Technical Specification:
Model | KF-P620 |
Working Speed | Max. 80m/min |
Capacity | 600cans/min |
Coating Width | 6～16mm |
Can Diameter | D52～D400mm |
Powder Material | PET, Epoxy Resin |
Compressed Air | 0.6mpa，0.5m3/min，Relative humidity＜60% |
Voltage | AC220V，60 HZ, Single phase |
Power | 2 KW |
