Product Features
The machine adopts the complete mechanical cam transmission, and mechanical cam conveying system.
The mechanical cam holding system for the can body to make the machine working smoothly and stably.
The speed is adjustable continuously, and the can jam protection system is equipped to make the machine working safely. The servo motors are adopted to make the machine working more precisely and better power energy saving.
Product Specifications
Model | Model: KF-20HL |
Function | Expending / Pre-flanging / Flanging / Beading/ Bottom Seaming / Turn over/ Lid seaming (Double seaming & Triple seaming are available) |
Capacity | 40-45CPM |
Can Diameter | D200-300mm |
Can Height | 180-500mm |
Connection Height | 1000±10mm |
Total Power | 30Kw |
Voltage | 380V/50Hz/3Phase |
Dimension | 16000*1900*3050mm |
Weight | 16000kg |
