E2-600KF
KAIFU
FEATURE:
The EOE making machine is made with the ingenious design and high precision processed.
For the shell system, the high speed double robots sheet feed press (CNC press) are available. For the conversion system, the Minster / Aida / Yadon press are available for choice. The conversion mould is made by a professional EOE technical team which is the longest history EOE tooling system manufacturer in China to make the high precision conversion mould with the craftman atitude, and the scientifically designed conversion system to reach the smooth and stable working performance to output the good quality EOE, and the long life time for the components of the conversion mould. We are doing the EOE making machines with different models: the single-output, and multi output (2-out, 3-out, 4-out) are available based on the customer’s requirement.
SPECIFICATION:
(For Conversion System)
Model | E2-600KF |
Press tonnage | 75-125MT |
Press speed | Max 650SPM |
Coversion system configuration | Output 1-4 lanes available for choice |
Output capacity | Max 2500EPM |
Diameter range | 202-603 |
Main power | 36-48KW |
